Interface
Interface
SATA 6Gb/s
Features
Drive Bays Supported
Up to 24-bay
Multi-User Technology (TB/yr)
300
Rotational Vibration (RV) Sensors
Yes
Hot-Plug Support
Yes
Cache (MB)
256
Reliability/Data Integrity
Mean Time Between Failures (MTBF, hours)
1,200,000
Reliability Rating @ Full 24×7 Operation (AFR)
0.73%
Nonrecoverable Read Errors per Bits Read, Max
1 per 10E15
Power-On Hours per Year (24×7)
8760
Sector Size (Bytes per Logical Sector)
512E
Rescue Services
Yes
Performance
Spindle Speed (RPM)
7200
Interface Access Speed (Gb/s)
6.0, 3.0, 1.5
Max. Sustained Transfer Rate OD (MB/s)
250MB/s
Average Latency (ms)
4.16
Interface Ports
Single
Rotational Vibration @ 10-1500 Hz (rad/s)
12.5
Power Consumption
Startup Current, Typical (12V, A)
2.0
Idle Power, Average (W)
5.0
Average Operating Power (W)
7.6W
Standby Mode (W)
1.0
Sleep Mode (W)
1.0
Power Supply Requirements
+12 V and +5 V
Environmental/Temperature
Operating (ambient, min °C)
5
Operating (drive case, max °C)
60
Nonoperating (ambient, min °C)
-40
Nonoperating (ambient, max °C)
70
Environmental/Acoustics
Vibration, Nonoperating: 10Hz to 500Hz (Grms)
2.27
Idle (typical)
2.8bels
Seek (typical)
3.2bels
Environmental/Shock
Shock, Operating 2ms (Read/Write) (Gs)
50/50Gs
Shock, Nonoperating, 1ms and 2ms (Gs)
200
Physical
Height (mm/in)
26.11mm/1.028in
Width (mm/in, max)
101.85mm/4.01in
Depth (mm/in, max)
146.99mm/5.787in
Weight (g/lb)
670g/1.477lb
